Diverge 4 Pro LTD
Overview
Overview
- Use: Gravel Adventure/Race
- Frameset: FACT 9r Carbon
- Suspension: Future Shock 3.3
- Drivetrain/Wheels: SRAM Red AXS XPLR with Quarq / Roval Terra CLX II
- Storage: SWAT 4.0
- 8.01kg
Technical Specifications
Technical Specifications
| Frame | Specialized Diverge FACT 9r carbon, SWAT™ Door integration, Future Shock suspension, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc, UDH dropout |
| Fork | Future Shock 3.3 w/ Smooth Boot, FACT Carbon 12x100mm, thru-axle, flat-mount disc |
| Wheels | Front: Roval Terra CLX II, 25mm internal width, Tubeless Ready, 32mm depth, 21h, Roval LF13 hub with ceramic SINC bearings, Centerlock disc, DT Swiss Aerolite spokesRear: Roval Terra CLX II, 25mm internal width, Tubeless Ready, 32mm depth, 24h, Roval LF14R2, Centerlock, DT Swiss EXP internals, SRAM XDR, DT Swiss Aerolite spokes |
| Tires | Tracer 700x45, Tan Sidewall, Tubeless Ready |
| Bottom bracket | SRAM DUB BSA 68 Wide |
| Crankset | SRAM Red AXS, Quarq Power Meter, 40t Chainring |
| Shifters | SRAM Red AXS E1 |
| Rear derailleur | SRAM Red XPLR, 13sp |
| Cassette/freewheel | SRAM Red XPLR, 13sp, 10-46t |
| Chain | SRAM Red E1 Chain |
| Brakes | SRAM Red AXS, hydraulic disc |
| Handlebars | Roval Terra, carbon, 103mm drop x 70mm reach x 12º flare |
| Tape/grips | Supacaz Super Sticky Kush |
| Stem | S-Works SL, alloy, titanium bolts, 6-degree rise |
| Seatpost | Roval Terra Carbon Seat Post, 20mm Offset |
| Saddle | S-Works Power with Mirror |
| Pedals | Sold Separately |
Parts are subject to change without notice. Chat with us if you have any questions.
Geometry
Geometry
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
| Stack (mm) (mm) | 563 | 578 | 592 | 610 | 634 | 659 |
| Reach (mm) (mm) | 365 | 374 | 387 | 400 | 412 | 425 |
| Head Tube Length (mm) (mm) | 90 | 104 | 116 | 135 | 161 | 187 |
| Head Tube Angle (°) | 70 | 70.5 | 71 | 71 | 71 | 71 |
| BB Drop (mm) (mm) | 85 | 85 | 85 | 85 | 85 | 85 |
| Trail (mm) (mm) | 72 | 68 | 65 | 65 | 65 | 65 |
| Fork Length, Full (mm) (mm) | 391 | 391 | 391 | 391 | 391 | 391 |
| Fork Rake/Offset (mm) (mm) | 55 | 55 | 55 | 55 | 55 | 55 |
| Front Center (mm) (mm) | 604 | 613 | 626 | 645 | 665 | 686 |
| Chainstay Length (mm) (mm) | 430 | 430 | 430 | 430 | 430 | 430 |
| Wheelbase (mm) (mm) | 1019 | 1031 | 1041 | 1060 | 1081 | 1102 |
| Top Tube Length, Horizontal (mm) (mm) | 521 | 537 | 556 | 575 | 593 | 613 |
| Bike Standover Height (mm) (mm) | 700 | 725 | 754 | 779 | 805 | 832 |
| Seat Tube Length (mm) (mm) | 400 | 430 | 470 | 500 | 530 | 560 |
| Seat Tube Angle (°) | 74.5 | 74 | 74 | 74 | 74 | 74 |
| Crank Length (mm) (mm) | 165 | 170 | 172.5 | 172.5 | 175 | 175 |
| Handlebar Width (mm) (mm) | 380 | 400 | 420 | 420 | 440 | 440 |
| Stem Length (mm) (mm) | 60 | 70 | 80 | 90 | 100 | 100 |
| Saddle Width (mm) (mm) | 155 | 155 | 143 | 143 | 143 | 143 |
| Seatpost Length (mm) (mm) | 330 | 330 | 380 | 380 | 380 | 380 |
This Geometry Chart is provided by the Manufactuer. Chat with us if you have any questions.
Sizing
Sizing
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
| height (cm) | 155-163 | 163-170 | 170-175 | 175-180 | 180-188 | 188-196 |
Sizing to be used as a reference only. Chat with us if you have any questions.
