Rigid

- Hi-tensile steel construction - Available with brake studs or without - 60mm rake - Type: Cruiser Size: 26" - Steerer Type: Threaded Steerer - Steerer Length: 250mm - Axle-to-Crown: 400mm - Axle: 3/8" - Thread Length: 125mm - O.L.D.: 100mm

Dimension Rigid Mountain Forks are intended for general recreational riding only; they are not intended for aggressive riding, stunt riding or road racing. - Forged dropouts with eyelets - Chromoly tubing - Cantilever mounts only (no disc mount) - Axle to Crown Length: 395mm - Brake Mount (Fork): Canti Studs - Color: Black - Crown Race: 30 - Front Axle: 10mm x 100mm - Maximum Tire Clearance (Fork): 3.8 - Offset: 45mm - S.H.I.S. Stem Clamp Diameter: 25.4-24 tpi Quill - Steerer Tube Length (mm): 140 - Steerer Type: Straight - Weight: 877g - Wheel Size: 26-inch

700c Hybrid fork with Cantilever Mounts - Forged dropouts with eyelets, straight-gauge oval-tapered blades - Dimension Forks are intended for general recreational riding only; they are not intended for aggressive riding, stunt riding or road racing - Welded unicrown construction - Clearance for 50mm wide fenders (1 1/8-inch) - Axle to Crown Length: 403mm (1 1/8-inch); 412mm (1 1/8-inch SC); 403mm (1-inch) - Brake Mount (Fork): Canti Studs - Color: Black - Crown Race: 30 (1 1/8-inch, 1 1/8-inch SC); 26 (1-inch) - Front Axle: 10mm x 100mm - Material: Steel - Offset: 50 mm - S.H.I.S. Stem Clamp Diameter: 28.6 (1 1/8-inch, 1 1/8-inch SC); 25.4 (1-inch) - Steerer Tube Length: 300mm (1 1/8-inch); 260mm (1 1/8-inch SC); 300mm (1-inch) - Steerer Type: Straight - Weight: 975g (1 1/8-inch); 1105g (1 1/8-inch SC); 963g (1-inch) - Wheel Size: 700c

- Forged dropouts with eyelets, straight-gauge oval tapered blades - Dimension Forks are intended for general recreational riding only; they are not intended for aggressive riding, stunt riding or road racing - 85mm threaded section - Fits up to 30c tires - Axle to Crown Length: 382 mm - Brake Mount (Fork): Long Reach Caliper (55mm - 73mm) - Crown Race: 27 - Front Axle: 9mm x 100mm - Material: Steel - Offset: 50mm - S.H.I.S. Stem Clamp Diameter: 25.4-24tpi Quill - Steerer Type: Straight - Weight: 839g, 876g, 907g - Wheel Size: 27"

Get back on the road with a genuine replacement fork for Electra Townie Commute bikes. Color matched for direct compatibility.

- Hi-Tensile steel construction - 135mm fat tire front hub spacing - Steerer Type: Threadless - Steerer Size: 1-1/8-inch - Steerer Length: 275mm - Brake Mount: Is Disc - Rake: 45mm - Axle-to-Crown: 450mm - Race Diameter: 30mm - Axle: QR 9mm

- Designed to match the Pake Rum Runner Track frames - Straight legs with unicrown CrMo construction - 300mm CrMo steerer with 38mm rake

From the pavement to the gravel, Origin-8's Cromo-Lite Disc Road Fork is made to explore. Crafted from super tough 4130 cromoly, it provides a comfortable ride with room for 28c tires for added control. And, it features mounts for disc or caliper brakes so you can ride your way.

- Add a disc brake to any track bike with IS disc mounts for 160mm rotor - Straight legs with unicrown CrMo construction - 300mm CrMo steerer - Forward facing dropouts for easy wheel removal - Black fork is designed to match the Pake Rum Runner Track frames

Origin-8's Cromo-Lite Combo Mountain Fork is seriously versatile. This 4130 chromoly steel fork can be used with 26- or 29-inch wheels, and is suspension corrected for a 100mm 26-inch-wheel fork. With disc mounts and linear-pull brake bosses, even your brake choices are versatile.

Origin-8's Cromo-Lite Combo Mountain Fork is a versatile fork for your 26-inch wheeled bike. Crafted from 4130 chromoly steel, it provides a compliant ride that's suspension corrected for excellent handling. With disc mounts and linear-pull brake bosses, you're set to mount the brakes you want.

Our lugged and brazed Cross-Check fork has room for 700c x 45mm tires and fenders. It’s made from 4130 CroMoly steel and features fender eyelets at the dropouts, cantilever brake pivots, and now has through-leg mid-blade eyelets for mounting a rack. The eyelets are threaded 5 x 1mm and located 165mm up from the axle. Finish is powdercoat. - Axle-to-crown: 400mm - Offset: 44mm - Steerer: 300mm - Tire Clearance: 700c x 45mm - Weight: 2.3 lb (1.0kg) uncut

The Long Haul Trucker fork is designed to mount racks and fenders and to haul stuff. Offered in 26? and 700c wheel sizes, the fork’s new crown provides ample clearance for 700c x 50mm tires, and sports threaded eyelets in four locations (dual dropout, midblade and fork crown) to provide more options for mounting stuff, from racks to whatever. Options galore. Curved blades, CroMoly steel. 1-1/8-inch threadless steer tube. - Axle-to-crown: 700c = 390mm - Offset: 45mm - Steerer: 700c (56–64cm frames) = 350mm - Tire Clearance: 700c x 45mm - Weight: 700c = 2.3 lb uncut

The Troll Fork is just like the one that comes with the Troll frame, a 26-inch wheeled fully geared utility bruiser and cruiser. Like all Surly's forks, it's constructed of CroMoly steel. It sports removable rim brake pivots as well as a 51mm disc caliper mount. The Troll Fork is designed to accept a rack while using a disc brake, via through-blade threaded mounts in two places on each fork blade, and it's even got fender eyelets. - Disc or rim brake compatible - Compatible with disc brakes and rack simultaneously - Fits 26-inch wheels with clearance for a 3.0-inch tire - Steerer Type: Straight 1-1/8-inch - Sleek powdercoat finish

Classic 100% chromoly construction and engineered for modern accessories, that's Surly's Long Haul Trucker Disc Fork. Its beautiful curved blades are brazed to a lovely and tough investment-cast crown and dropouts. There are disc-brake mounts and eyelets for fenders and mounts for a standard or low-rider rack. Plus, it boasts a tough powdercoat finish that's tres chic. - 100% CroMoly steel construction, curved blades, powdercoated - Extensive mounting options with threaded eyelets in four locations: double eyelet dropouts, mid-blade, and a pair drilled into the fork crown - 51mm IS disc brake mount - 700c has clearance for a 45mm tire

The Straggler fork is very much like the Cross-Check fork — it's a lugged and brazed CroMoly fork with room for 700c tires up to 50mm wide. Both feature fender and rack mount eyelets at the dropouts, mid-blade threaded rack mounts and threaded eyelets on the sides of the crown for accessories. Both deliver a resilient ride and are finished in black powdercoat. The Straggler fork is equipped with a 51mm I.S. disc caliper mount and no accommodation for rim brakes. - Axle-to-crown: 400mm - Offset: 44mm - Steerer: 300mm, 1-1/8" straight (42-58cm), 350mm, 1-1/8" straight (60-62cm) - Tire Clearance: 50mm (w/o fender) Weight: 2.5 lb (1.15kg) uncut

Made from revised 100% Cult Classic tubing for increased strength and then 100% post-weld heat treated. Investment cast 1pc drop outs for maximum strength and a super sleek finish. Features an updated top cap retention design. - 1-pc machined steerer tube with an integrated bearing race - Tapered legs - Tire clearance for 2.40” tires - Updated top cap retention design

Odyssey's 41-Thermal forks quickly established a reputation for strength and quality when originally introduced in 1999, and they have since gone on to change the standards that all forks are judged by. Features: - Fully redesigned - Laboratory tested and team proven - New, custom, seamless, tapered, butted and specially formed leg tube shaping for improved grind and guard clearance - All-new steerer tube design improves fatigue strength and includes a built-in, integrated, lower headset seat race - New, optimized, 4mm dropout shape for grind and peg clearance - Updated 7075-T6 pre-load bolt, US Pat. No. 7,591,474 - Proven 41-Thermal processed 4130 chromoly - Legendary lifetime replacement warranty Specs: - 25mm steep offset - 3/8-inch axle slots only - 990 brake mounts - Starting at 2lb 2oz (912 grams)

- Chromoly steel BMX style forks - Perfect replacement for modern BMX-inspired wheelie bikes - Steerer Type: Threadless - Steerer Size: 1-1/8-inch - Material: Chromoly - Race Diameter: 30mm - Axle: 3/8-inch

Odyssey's 41-Thermal forks quickly established a reputation for strength and quality when they originally introduced them in 1999, and they have since gone on to change the standards that all forks are judged by. The new R-Series forks continue this tradition. FEATURES - Fully redesigned. - Laboratory tested and team proven. - New, custom, seamless, tapered, butted and specially formed leg tube shaping for improved grind and guard clearance. - All-new steerer tube design improves fatigue strength and includes a built-in, integrated, lower headset seat race. - New, optimized, 4mm dropout shape for grind and peg clearance. - Updated 7075-T6 pre-load bolt - Proven 41-Thermal® processed 4130 chromoly - Legendary lifetime replacement warranty SPECS - 25mm traditional offset - 3/8” axle slots only Starting at 1lb 15.2oz (885 grams)

Our XC forks are ideal for your next rigid mountain bike project. We designed these forks to compliment all bikes, with CNC steerer tube and full chromoly construction. - Tapered, multi-butted legs - QR dropouts - Tig-welded together and post weld heat treated for ultimate rigidity and durability - Custom forged drop outs

- Lightweight alternative to suspension forks - Butted 31.8mm 4130 CrMo straight blades with shallow radius leg bends - Internally and externally butted steerer reduces weight, minimizes stress risers - 6mm thick CNC machined dropouts with safety lip feature (10mm dropout) - 51mm International Standard disc brake mounts. The 425mm axle-to-crown version can also fit 700 x 38c wheel/tire, maintaining low axle to crown height). 3.1lbs (200mm uncut)

Made from revised 100% Cult Classic tubing for increased strength and then 100% post-weld heat treated. 1-pc machined steerer tube with an integrated bearing race, tapered legs, and plenty of tire clearance.

Get back on the road with a genuine replacement fork. The fork you need. - Original replacement fork - Color matched for direct compatibility

Laterally stiff and fine riding steel-lugged cross fork. Features a sloping lugged crown with cutouts on outside tangs, long inside tangs, and an International Standard disc tab. - Tange Infinity chromoly steel blades and steerer - Rack eyelets for fenders and braze-ons for low-rider panniers - 1 1/8" threadless steerer - 350mm long steerer - 44mm rake - 400mm axle to crown - 60mm inside width - Lugged Cross fork to match Double Cross Cyclocross frames - Lugged crown with Tange CrMo construction - Features eyelets for front rack and braze-ons for low-rider panniers

Lugged investment cast crown with cutout in outside tang, long inside tang. Crown drilled for brake. Tange CrMo steel steerer tube and blades. - 1" steerer tube, threadless, 300mm long. - 369mm axle to crown - 38mm and 30mm(only in black) rake. - Lugged crown with Tange Infinity CrMo construction - Threaded models have 50mm of thread - All accept a standard road caliper brake

- Designed for cantilever brakes - Tange Infinity CrMo steel blades with D-shaped cross section - Fender eyelets at fork tips - Low rider pannier rack eyelets - Steerer 1-1/8", 350mm long, CrMo - Axle to crown 400mm - 44mm rake - Anti-rust coating - Max tire clearance 700c x 40mm (27.5 x 2.0") - Black

Odyssey's 41-Thermal forks quickly established a reputation for strength and quality when they originally introduced them in 1999, and they have since gone on to change the standards that all forks are judged by. Their new R-Series forks continue this tradition. FEATURES - Fully redesigned. - Laboratory tested and team proven. - New, custom, seamless, tapered, butted and specially formed leg tube shaping for improved grind and guard clearance. - All-new steerer tube design improves fatigue strength and includes a built-in, integrated, lower headset seat race. - New, optimized, 4mm dropout shape for grind and peg clearance. - Updated 7075-T6 pre-load bolt - Proven 41-Thermal® processed 4130 chromoly - Legendary lifetime replacement warranty SPECS - 32mm traditional offset - 3/8” axle slots only Starting at 1lb 15.2oz (885 grams)

Like its QR cousin, the Disc Trucker Thru-Axle Fork is designed to mount racks and fenders and haul your worldly possessions. It's also got modern touches like dynamo routing, compatibility with flat-mount disc brakes, and three-pack mounts on both fork blades to satisfy your deepest cargo desires. Captured 12mm thru-axles make tool-free removal and installation possible. Offered in 26" and 700c wheel sizes, the Thru-Axle fork clears 26 x 2.1" or 700c x 47mm tires. With a 1-1/8" steerer, it's powder-coated and constructed using the same Chromoly steel as all our other frames and forks. Why? Because we swore a blood oath to steel and we intend to keep it. Note: The Disc Trucker TA Fork is designed to pair best with second-generation Disc Trucker models—those first released in 2020. Defy this guidance at your own peril. 26 Inch - Axle-to-crown: 376mm - Offset: 45mm - Steerer: 42–54cm frames = 300mm, 1-1/8" straight - 56–62cm frames = 400mm, 1-1/8" straight - Tire Clearance: 26 x 2.1" (with or without fenders) 700c - Axle-to-crown: 390mm - Offset: 45mm - Steerer: 56–64cm frames = 350mm, 1-1/8" straight - Tire Clearance: 700c x 47mm (with or without fenders)

The Ice Cream Truck fork is made from 4130 CroMoly steel and is designed for Surly's Ice Cream Truck frame. It's ready for trail use and features butted and tapered blades with thru-axle dropouts spaced at 150mm. It has barrel bosses at the dropouts and crown, mid-blade thru-blade eyelets and triple bottle bosses on both fork legs. That's a lot of bosses. 51mm I.S. mounts use front disc spacing. - Axle-to-crown: 483mm - Offset: 47mm - Steerer: 260mm, 1-1/8-inch straight - Tire Clearance: 26 x 5.25-inch
