2025 Domane+ AL 5 Electric Road Bike
Overview
Overview
Technical Specifications
Technical Specifications
| Frame | 100 Series Alpha Aluminum, hub drive system, tapered head tube, internal routing, flat mount disc, rack and fender mounts |
| Fork | Domane+ carbon, tapered alloy steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle |
| Weight | 56 - 14.10 kg / 31.09 lbs |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg). |
| Battery | 250Wh, integrated in down tube |
| Charger | 2A, 42V output, 100V-240V AC input |
| Motor | Hyena hub drive motor, 40Nm, 250W |
| E-bike classification | Class 1 |
| Shifter | Shimano 105 R7120, 12 speed |
| Front derailleur | Shimano 105 R7100, 31.8mm clamp, down swing |
| Rear derailleur | Shimano 105 R7100, 36T max cog |
| *crank | Size: 49 FSA Vero Pro, 50/34, 165mm lengthSize: 52 FSA Vero Pro, 50/34, 170mm lengthSize: 54, 56 FSA Vero Pro, 50/34, 172.5mm lengthSize: 58, 61 FSA Vero Pro, 50/34, 175mm length |
| Bottom bracket | Torque sensor, threaded, 110mm spindle |
| Cassette | Shimano 105 7101, 11-34, 12 speed |
| Chain | Shimano SLX M7100, 12 speed |
| Max chainring size | 2x: 50/34 |
| Hub front | Formula RX-812 alloy, sealed bearing, 6-bolt, 100x12mm thru axle |
| Skewer front | Bontrager Switch thru axle |
| Rim | Bontrager Paradigm, Tubeless Ready, 28-hole, 21mm width, Presta valve |
| Tire | Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x32mm |
| Max tire size | 38mm without fenders, 32mm with fenders |
| Saddle | Bontrager Verse P3, steel rails |
| Seatpost | Bontrager carbon, 27.2mm, 8mm offset, 330mm length |
| *handlebar | Size: 49 Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 38cm widthSize: 52 Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 40cm widthSize: 54, 56 Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 42cm widthSize: 58, 61 Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 44cm width |
| Handlebar tape | Bontrager Supertack Perf tape |
| *stem | Size: 49 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm lengthSize: 52, 54 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm lengthSize: 56, 58 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm lengthSize: 61 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 110mm length |
| Headset | FSA Integrated, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom |
| Brake rotor | Shimano RT66, 6-bolt, 160mm |
| Rotor size | Max brake rotor sizes: 160mm front & rear |
Parts are subject to change without notice. Chat with us if you have any questions.
Geometry
Geometry
All measurements provided in cm unless otherwise noted.
| Frame size number | 49 cm | 52 cm | 54 cm | 56 cm | 58 cm | 61 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| A — Seat tube | 44.0 | 47.5 | 50.0 | 52.5 | 54.8 | 56.7 |
| B — Seat tube angle (degrees) | 74.6° | 74.2° | 73.7° | 73.3° | 73.0° | 72.7° |
| C — Head tube length | 11.0 | 13.0 | 14.5 | 16.0 | 18.0 | 22.0 |
| D — Head angle (degrees) | 70.8° | 71.3° | 71.3° | 71.9° | 72.0° | 72.1° |
| E — Effective top tube | 51.7 | 53.0 | 54.2 | 55.4 | 56.7 | 58.6 |
| G — Bottom bracket drop | 8.0 | 8.0 | 8.0 | 7.8 | 7.8 | 7.8 |
| H — Chainstay length | 43.0 | 43.0 | 43.0 | 43.0 | 43.0 | 43.0 |
| I — Offset | 5.3 | 5.3 | 5.3 | 4.8 | 4.8 | 4.8 |
| J — Trail | 6.7 | 6.4 | 6.4 | 6.5 | 6.5 | 6.4 |
| K — Wheelbase | 100.7 | 101.3 | 102.1 | 101.8 | 102.7 | 104.3 |
| L — Standover | 72.7 | 75.3 | 77.2 | 79.4 | 80.9 | 82.5 |
| M — Frame reach | 36.8 | 37.1 | 37.4 | 37.7 | 38.0 | 38.5 |
| N — Frame stack | 54.0 | 56.1 | 57.5 | 59.1 | 61.1 | 64.6 |
| Stem length | 80.0 | 90.0 | 90.0 | 100.0 | 100.0 | 110.0 |
This Geometry Chart is provided by the Manufactuer. Chat with us if you have any questions.
Sizing
Sizing
| size | inches | cm |
|---|---|---|
| 49 | 5'1" - 5'4" | 156 - 163 |
| 52 | 5'4" - 5'6" | 163 - 168 |
| 54 | 5'6" - 5'9" | 168 - 174 |
| 56 | 5'9" - 5'11" | 174 - 180 |
| 58 | 5'11" - 6'1" | 180 - 185 |
| 61 | 6'1" - 6'3" | 185 - 191 |
Sizing to be used as a reference only. Chat with us if you have any questions.
