Ponto Go! 20/US OSFM Cloud
Fully assembled, tuned, and test-ridden—ready to ride at pickup from any DFW Bike Mart location.
Expected to ship within 3 days
Professionally built and test-ridden before it ships. Arrives mostly assembled with just minimal setup needed. See Reassembly Instructions
Delivered fully assembled and tuned by Bike Mart—ready to ride right at your doorstep within 10 miles of any DFW location.
Ship
Get your bike or equipment delivered to your home directly from Bike Mart via our FedEx or USPS Carrier partners. Adult signature is required for all bike deliveries and for equipment & gear deliveries over $500.
For orders that include a bike, it will be professionally pre-built and shipped to your home with minimal assembly needed. While we try to make it as easy as possible, basic mechanical skills and proper tools are required. For orders that include a frameset please visit our support center to make sure you have the specialty tools and skills required.
If you decide to take your bike to a local retailer for assembly, additional fees will apply.
Pickup
We’ve made it easier than ever to get the gear and bikes you love—fast. With our Buy Online, Pick Up In Store (BOPIS) option, you can shop online and pick up your items at your convenience from any of our six DFW locations.
The best part about picking up at a Bike Mart location is that you get the same high quality service with the convenience of having the exact bike or part.
Bikes / Car Racks will be assembled and installed at no extra charge
Delivery
When you select "Home Delivery" at checkout. Your bike will be professionally assembled and the closest Bike Mart store will call you to schedule the delivery.
We offer home delivery for bike purchases only within 10 miles of a Bike Mart location. Contact us if you live beyond 10 miles and we can discuss more options. Additional fees may apply.
In stock bikes will be delivered within 7 days. Warehouse bikes will delivered within 14 days*.
Ponto Go! 20/US OSFM Cloud
-
Bike Safety 101
Being safe doesn’t have to be boring. That’s why we broke down the basics for safe riding, especially when it comes to getting around on an e-bike.
-
Accessorize your Ponto Go!
This e-bike can do a lot on its own, but add a front tray, bag, or surf carrier to maximize what it can do. Some products were made specifically with Ponto Go! in mind, while others like a helmet, bell and lock just make sense.
-
Compliant with leading safety regulations
The e-systems on Trek and Electra e-bikes are third-party tested to meet the latest e-bike safety regulations, including the stringent UL 2849 certification — so all you have to worry about is where your e-bike will take you next.
Overview
Overview
Technical Specifications
Technical Specifications
| Frame | 6061-T6 aluminum |
| Fork | HL suspension fork, 80mm travel, coil spring |
| Front hub | Alloy, 36H, 12G spoke drilling, 135mm |
| Rims | Alloy, 20\x57mm, 36h, 12G spoke drilling |
| Tires | 20x4.0\ heavy duty, 160Kg rated, reflective |
| Shifters | MicroShift trigger, w/optical gear indicator, 8-speed |
| Rear derailleur | MicroShift Mezzo, 8-speed |
| Crank | Alloy, forged, square taper, 160mm length |
| Bottom bracket | Double sided BB torque sensor |
| Cassette | Freewheel, 11-34T, 8-speed |
| Chain | KMC Z8.3 RB, rust resistant |
| Pedals | Resin platform w/grip tape tread |
| Saddle | Electra custom front saddle, Electra custom rear saddle |
| Seatpost | Alloy passenger handle |
| Handlebar | Electra custom alloy |
| Grips | Electra custom kraton, alloy lock-on, 132mm length |
| Stem | Electra custom alloy with integrated shroud |
| Headset | 1.5\, sealed cartridge bearing |
| Brakeset | Tektro HD-E395 hydraulic disc w/switch, 180x2.3mm rotor |
| Battery | 625Wh removable, lockable battery |
| Controller | HMI display with thumb throttle |
| Motor | BEP hub drive motor, 60Nm, 36h |
| Front light | Herrmans H-Black MR9-E |
| Rear light | Sate-Lite M-13 w/turn signal and brake light function |
| Kickstand | Alloy, rear mount |
| Weight | 36.29 kg / 80.01 lbs |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 440 pounds (199 kg). |
Parts are subject to change without notice. Chat with us if you have any questions.
Geometry
Geometry
All measurements provided in cm unless otherwise noted.
| Frame size letter | One size |
| Wheel size | 20" |
| A — Seat tube | 47.3 |
| C — Head tube length | 16.9 |
| D — Head angle (degrees) | 66.0° |
| I — Offset | 4.3 |
| K — Wheelbase | 120.2 |
| L — Standover | 56.0 |
| M — Frame reach | 28.2 |
| N — Frame stack | 52.7 |
This Geometry Chart is provided by the Manufactuer. Chat with us if you have any questions.
Sizing
Sizing
| size | inches | cm |
|---|---|---|
| One size fits most | 4'11" - 6'10" | 150 - 208 |
Sizing to be used as a reference only. Chat with us if you have any questions.
