2026 Checkmate SLR Gravel Road Frameset
-
Our fastest gravel bike ever
New Full System aero tube shapes and an aero-yet-ergonomic one-piece barstem help make Checkmate our fastest gravel bike to date.
-
Our lightest gravel bike ever
Premium components and 800 Series OCLV Carbon keep things light and fast for ultimate race-day performance.
-
IsoSpeed comfort tech
Isospeed compliance tech absorbs fatiguing bumps in the road to keep you riding stronger longer.
-
Plenty of tire clearance
Room for gravel tires up to 45mm wide (as measured) keep you smooth and fast on quick courses and gnarly terrain.
-
Race-optimized gear storage
Multiple frame mounts let you add Adventure Bags to carry your race-day essentials while leaving room for ample hydration.
-
New Gravel Race geo
This brand-new geometry was designed specifically for gravel racing to keep you tucked out of the wind, nimble on corners, and in control on descents and rougher roads.
-
Design your custom Checkmate
Choose from a seemingly endless palette of colors, cherrypick your components, and find yourperfect fit with our Project One bike program.
-
The bike of the pros
Checkmate is the bike of choice for pro gravel riders on the Trek Driftless team.
Overview
Overview
Technical Specifications
Technical Specifications
| Frame | 800 Series OCLV Carbon, IsoSpeed, hidden fender mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12mm chamfered thru axle |
| Fork | Checkmate SLR full carbon, tapered carbon steerer, hidden fender mounts, flat mount disc, 12x100mm thru axle |
| Weight | 1146g - ML (frame-only, painted), 415g (fork-only, painted) |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg). |
| Max chainring size | See service manual |
| Skewer front | Bontrager Switch chamfered thru axle |
| Skewer rear | Bontrager Switch chamfered thru axle, removable lever |
| Max tire size | 45mm without fenders, 38mm with fenders (as measured, see manual for details) |
| Rotor size | Max brake rotor sizes: 180mm front & rear |
Parts are subject to change without notice. Chat with us if you have any questions.
Geometry
Geometry
All measurements provided in cm unless otherwise noted.
| Frame size letter | XS | S | M | ML | L | XL |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| A — Seat tube | 37.3 | 41.4 | 45.5 | 50.0 | 53.7 | 58.3 |
| B — Seat tube angle (degrees) | 73.9° | 73.9° | 73.7° | 73.5° | 73.6° | 73.7° |
| C — Head tube length | 9.1 | 10.6 | 12.6 | 15.0 | 17.4 | 19.9 |
| D — Head angle (degrees) | 71.0° | 71.3° | 71.5° | 71.7° | 72.0° | 72.4° |
| E — Effective top tube | 53.2 | 54.0 | 55.5 | 57.0 | 58.1 | 59.2 |
| G — Bottom bracket drop | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 |
| H — Chainstay length | 42.6 | 42.6 | 42.6 | 42.6 | 42.6 | 42.6 |
| I — Offset | 4.9 | 4.9 | 4.9 | 4.9 | 4.9 | 4.9 |
| J — Trail | 7.2 | 7.0 | 6.8 | 6.7 | 6.5 | 6.2 |
| K — Wheelbase | 100.3 | 101.1 | 102.2 | 103.5 | 104.5 | 105.4 |
| L — Standover | 71.8 | 74.7 | 78.2 | 81.6 | 85.1 | 88.6 |
| M — Frame reach | 38.0 | 38.5 | 39.2 | 39.9 | 40.4 | 40.9 |
| N — Frame stack | 52.5 | 54.0 | 56.0 | 58.4 | 60.8 | 63.3 |
| Saddle rail height min (w/short mast) | 54.6 | 58.7 | 62.8 | 66.8 | 72.0 | 75.1 |
| Saddle rail height max (w/short mast) | 61.1 | 65.2 | 69.3 | 73.3 | 78.5 | 81.6 |
| Saddle rail height min (w/tall mast) | 58.6 | 62.7 | 66.8 | 70.8 | 76.0 | 79.1 |
| Saddle rail height max (w/tall mast) | 65.1 | 69.2 | 73.3 | 77.3 | 82.5 | 85.6 |
This Geometry Chart is provided by the Manufactuer. Chat with us if you have any questions.
Sizing
Sizing
| size | inches | cm |
|---|---|---|
| XS | 4'8" - 5'2" | 143 - 158 |
| S (49cm) | 5'2" - 5'5" | 158 - 164 |
| M (52-54cm) | 5'5" - 5'10" | 164 - 177 |
| ML (56cm) | 5'10" - 6'2" | 177 - 188 |
| L (58cm) | 6'2" - 6'4" | 188 - 194 |
| XL (61cm) | 6'4" - 6'8" | 194 - 203 |
Sizing to be used as a reference only. Chat with us if you have any questions.
