2026 XTC Advanced 29 1 Full Suspension Mountain Bike
-
Advanced Composite Technology
Giant’s High Performance Grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle of these framesets is assembled and molded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.
-
Tubeless System
Fewer flat tires. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.
-
OverDrive
Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
Overview
Overview
Techs & Features:
Advanced Composite Technology
Giant’s High Performance Grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle of these framesets is assembled and molded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.
OverDrive
Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4" lower and 1 1/8" upper for road, 1 1/2" lower and 1 1/8" upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
Tubeless System
Fewer flat tires. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.
Technical Specifications
Technical Specifications
| Sizes | S, M, L, XL |
| Colors | Abyss Black/Steampunk |
| Frame | Advanced-grade composite, 12x148mm thru-axle |
| Fork | Fox 32 Float Step Cast Performance, 100mm, GRIP damper, 44mm offset, two-position remote lockout, Boost 15x110 Kabolt |
| Shock | N/A |
| Handlebar | Giant Contact XC 35, 760x35mm |
| Grips | Giant XC Pro S:32mm, M:32mm, L:34mm, XL:34mm |
| Stem | Giant Contact SL XC 35 S:60mm, M:70mm, L:80mm, XL:90mm |
| Seatpost | Giant Contact Switch Core dropper, remote S: 100mm travel / 30.9 x 350mm M: 100mm travel / 30.9 x 350mm L: 120mm travel / 30.9 x 400mm XL |
| Saddle | Giant Grit SL |
| Shifters | Shimano Deore XT M8100, 1x12 |
| Front derailleur | N/A |
| Rear derailleur | Shimano Deore XT M8100 |
| Brakes | Shimano Deore XT BR-M8100, hydraulic, Giant TR55 rotors [F]180mm, [R]160mm |
| Brake levers | Shimano Deore XT BL-M8100 |
| Cassette | Shimano SLX M7100, 10x51 |
| Chain | KMC X-12 |
| Crankset | Shimano Deore XT M8120, 32t S:170mm, M:175mm, L:175mm, XL:175mm |
| Bottom bracket | Shimano, press fit |
| Rims | Giant XCR 2 Carbon 29 WheelSystem |
| Hubs | [F] Giant MTB alloy, 6-bolt, [R] Giant MTB alloy, 3-pawl driver, 6-bolt |
| Spokes | Sapim |
| Tires | [F] Maxxis Rekon Race, 29x2.4, [R] Maxxis Rekon Race, 29x2.25, foldable, TLR, EXO |
| Extras | tubeless prepared, 2.25\ max tire size, 38t max chainring size |
Parts are subject to change without notice. Chat with us if you have any questions.
Geometry
Geometry
All measurements provided in mm unless otherwise noted.
| S | M | L | XL | |
| ASeat Tube Length (mm) | 380 | 431 | 475 | 525 |
| A1A1 Seat Post Insertion Depth (mm) | 165 | 220 | 260 | 310 |
| BSeat Tube Angle (degrees) | 73.5° | 73.5° | 73.5° | 73.5° |
| CTop Tube Length (mm) | 595 | 614 | 635 | 665 |
| DHead Tube Length (mm) | 95 | 95 | 105 | 115 |
| EHead Tube Angle (degrees) | 69.5° | 69.5° | 70.0° | 70.0° |
| FFork Rake (mm) | 43 | 43 | 43 | 43 |
| GTrail (mm) | 95 | 95 | 95 | 95 |
| HWheelbase (mm) | 1087 | 1106 | 1128 | 1159 |
| IChain Stay Length (mm) | 425 | 425 | 425 | 425 |
| JBottom Bracket Drop (mm) | 58 | 58 | 58 | 58 |
| KStack (mm) | 604 | 604 | 613 | 632 |
| LReach (mm) | 416 | 435 | 453 | 477 |
| MStand Over Height (mm) | 737 | 764 | 791 | 829 |
| NHandlebar Width (mm) | 760 | 760 | 760 | 760 |
| OStem Length (mm) | 60 | 70 | 80 | 90 |
| PCrank Length (mm) | 170 | 175 | 175 | 175 |
This Geometry Chart is provided by the Manufactuer. Chat with us if you have any questions.
Sizing
Sizing
| size | inches | cm |
|---|---|---|
| S | 5’4” - 5’8” | 163 - 172 |
| M | 5’7” - 5’11” | 171 - 180 |
| L | 5’10” - 6’2” | 179 - 188 |
| XL | 6’2” - 6’6” | 187 - 198 |
Sizing to be used as a reference only. Chat with us if you have any questions.
