Overview
Overview
- 100% Surly Chromoly frame, main triangle is double-butted; 1-1/8" threadless Chromoly fork
- Rack, fender, and four sets of three-pack mounts
- Disc brake-specific, single-position vertical rear dropout makes it less intimidating than other bikes in the category
- Clearance for 700 x 47mm (with or without fenders) or 27.5 x 2.8" tires (27.5 x 2.6" with fenders)
Technical Specifications
Technical Specifications
| Frame | Bridge Club - 100% Chromoly Steel frame, Natch tubing, double-butted main triangle, TIG welded, E.D. coated |
| Fork | Bridge Club - 100% Chromoly Steel fork, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated |
| Rims | WTB ST i29 TCS, 32h |
| Hubs | Front Hub Novatec 9x100mm QR, 6-bolt discRear Hub Novatec 10x141mm QR, 6-bolt disc |
| Spokes | 14G Black |
| Tires | WTB Trail Boss 27.5 x 2.4\, 27tpi, wire bead |
| Bottom bracket | Shimano MT501 |
| Crankset | Shimano Cues, 32t |
| Shifters | Shimano Cues |
| Rear derailleur | Shimano Cues |
| Cassette/freewheel | Shimano Cues, 11-50t, 11-speed |
| Chain | KMC |
| Brakes | Tektro Hydraulic, Tektro 160/160, 6-bolt |
| Handlebars | Salsa Bend |
| Tape/grips | Velo Black |
| Stem | Promax, 31.8mm |
| Headset | Cane Creek 40 Series, 1-1/8\ Threadless |
| Seatpost | Promax 27.2 x 350mm, 12mm offset |
| Saddle | WTB Volt |
| Pedals | Sold separately |
Parts are subject to change without notice. Chat with us if you have any questions.
Geometry
Geometry
| Frame measurements (mm) (mm) | X-Small | Small | Medium | Large | X-Large |
| A. BB Drop | 60 | 60 | 60 | 60 | 60 |
| B. Chainstay Length | 435 | 435 | 435 | 435 | 435 |
| C. Fork Length - Axle to Crown | 420 | 420 | 420 | 420 | 420 |
| D. Fork Offset | 43 | 43 | 43 | 43 | 43 |
| E. Head Tube Angle (deg) | 70 | 71 | 71 | 71 | 71 |
| F. Headtube Length | 110 | 120 | 130 | 145 | 165 |
| G. Reach | 376 | 397 | 419 | 434.5 | 444 |
| H. Seat Tube Angle (deg) | 73 | 73 | 73 | 73 | 73 |
| I. Seat Tube Length - Center to Top | 335.6 | 406.4 | 457.2 | 508 | 558.8 |
| J. Stack | 553 | 567 | 576 | 590 | 609 |
| K. Standover | 709 | 750.5 | 780 | 812 | 845.5 |
| L. Top Tube Length (Effective) | 545 | 570 | 595 | 615 | 630 |
| M. Wheelbase | 1032 | 1047.5 | 1073 | 1093 | 1109 |
| Crank Arm Length | 170 | 170 | 175 | 175 | 175 |
| Handlebar Width | 700 | 700 | 740 | 740 | 740 |
| Stem Length | 80 | 80 | 90 | 100 | 100 |
| Stem Angle (deg) | 0 | 0 | 0 | 0 | 0 |
This Geometry Chart is provided by the Manufactuer. Chat with us if you have any questions.
Sizing
Sizing
| Rider Height(Feet/Inches) | Rider Height (CM) | Bike Size | Frame Size (CM) |
| 5'0" - 5'5" | 152 cm - 165 cm | XS | 38 - 46 cm |
| 5'4" - 5'8" | 162 cm - 173 cm | SM | 50 - 54 cm |
| 5'7" - 6'0" | 170 cm - 183 cm | MD | 52 - 56 cm |
| 5'11" - 6'3" | 180 cm - 190 cm | LG | 54 - 58 cm |
| 6'2" - 6'6" | 188 cm - 198 cm | XL | 58 - 62 cm |
| 6'5" - 6'8" | 196 cm - 203 cm | XXL | 60 - 64 cm |
Sizing to be used as a reference only. Chat with us if you have any questions.
