2024 Avail Advanced 1 Road Bike
-
Advanced Composite Technology
Liv’s High-Performance Grade raw carbon material is used to produce this frameset in our own composite factory. Using state-of-the-art materials and manufacturing techniques, Liv’s Advanced-Grade Composite frames are designed to offer light weight and stiffness with optimal compliance.
-
Compact Road Design
When introduced by Giant in 1990s, Compact Road revolutionized the look and feel of high-performance road bikes forever. A downward sloping toptube (from the headtube to the seattube) creates smaller front and rear triangles for a lighter, stiffer bike. It also makes it easier for riders of all sizes to have a perfect fit.
-
D-Fuse Seatpost
The proprietary “D” shaped composite seatpost damps vibration, resulting in a smooth, compliant ride.
-
OverDrive
Designed to provide precise front-end steering performance, this fork steerer tube technology uses oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
-
Tubeless System
Engineered with proprietary Dynamic Balanced Lacing technology, this tubeless ready composite WheelSystem delivers superior efficiency, pinpoint control and comfort.
Overview
Overview
The Avail Advanced is that riding buddy who’s up for any adventure on the road—from solo backroad explorations to after-work shop rides to all-day epic rides with friends. Designed for performance and capable on any surface, this road warrior is ready to take you as far as you can go, which is always farther than you think.
Key Performance Factors
- Lightweight Advantage: The Avail Advanced delivers lightweight efficiency, thanks to an all-new Advanced-grade composite frame and an Advanced-grade composite fork, which boosts your climbing abilities and makes you virtually uncatchable over long distances.
- Superior Compliance: Ride longer without riding harder, with the reengineered frame and fork, optimized for the smoothest, most efficient riding experience. The innovative Liv Contact D-Fuse handlebar and D-Fuse seatpost absorb more road vibrations than round-shaped tubing, without sacrificing efficiency on corners and climbs.
- Maximum Control: The Liv Contact D-Fuse handlebar features an ergonomic shape and 8-degree flare drop, for total control on those sunrise-to-sunset rides. Wide, alloy rims are designed for high-volume tubeless tires (up to 38mm), providing predictable handling and stability from asphalt to pavé.
Technical Specifications
Technical Specifications
| Sizes | XS, S, M, L |
| Colors | Shoreline/Black |
| Frame | Advanced-grade composite, 12x142mm thru-axle, disc |
| Fork | Advanced-grade composite, full-composite OverDrive steerer, stainless steel bearings 12x100mm, disc |
| Shock | N/A |
| Handlebar | Liv Contact SL D-Fuse, 31.8mm, 8-degree flare drop XXS: 410/380mm, XS: 410/380mm, S: 430/400mm, M: 430/400mm, L: 450/420mm |
| Grips | Liv All Condition |
| Stem | Giant Contact AeroLight XXS: 70mm, XS: 70mm, S: 80mm, M: 90mm, L: 90mm |
| Seatpost | Giant Contact D-Fuse, composite, 14mm offset XXS: 350mm, XS: 350mm, S: 350mm, M: 350mm, L: 350mm |
| Saddle | Liv Approach |
| Pedals | N/A |
| Shifters | Shimano 105 Di2 |
| Front derailleur | Shimano 105 Di2 |
| Rear derailleur | Shimano 105 Di2 |
| Brakes | Shimano 105 Di2 hydraulic, Giant MPH rotors [F]160mm, [R]160mm |
| Brake levers | Shimano 105 Di2 hydraulic |
| Cassette | Shimano 105, 12-speed, 11x36 |
| Chain | KMC X12 |
| Crankset | Shimano 105, 34/50 XXS: 165mm, XS: 165mm, S: 170mm, M: 170mm, L: 172.5mm |
| Bottom bracket | Shimano, press fit |
| Rims | Giant P-R2 Disc wheelset |
| Hubs | Giant alloy, 12mm thru-axle |
| Spokes | Sapim |
| Tires | Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding |
| Extras | tubeless prepared, two bottle cages, 38mm max tire size, fender mount, computer mount |
Parts are subject to change without notice. Chat with us if you have any questions.
Geometry
Geometry
All measurements provided in mm unless otherwise noted.
| XS | S | M | L | |
| ASeat Tube Length (mm) | 405 | 435 | 465 | 495 |
| BSeat Tube Angle (degrees) | 74.5° | 74.5° | 74.0° | 74.0° |
| CTop Tube Length (mm) | 520 | 525 | 535 | 555 |
| DHead Tube Length (mm) | 125 | 145 | 165 | 185 |
| EHead Tube Angle (degrees) | 71.0° | 71.0° | 71.0° | 72.0° |
| FFork Rake (mm) | 50 | 50 | 50 | 50 |
| GTrail (mm) | 68 | 68 | 68 | 61 |
| HWheelbase (mm) | 995 | 1002 | 1007 | 1013 |
| IChain Stay Length (mm) | 420 | 420 | 420 | 420 |
| JBottom Bracket Drop (mm) | 75 | 73 | 73 | 73 |
| KStack (mm) | 528 | 547 | 566 | 589 |
| KStack to handlebar (mm) | 606 | 626 | 647 | 668 |
| LReach (mm) | 373 | 373 | 373 | 381 |
| LReach to handlebar (mm) | 420 | 429 | 439 | 449 |
| MStand Over Height (mm) | 712 | 737 | 762 | 789 |
| NHandlebar Width (mm) | 380 | 400 | 400 | 420 |
| OStem Length (mm) | 70 | 80 | 90 | 90 |
| PCrank Length (mm) | 165 | 170 | 170 | 172.5 |
| QWheel Size | 700C | 700C | 700C | 700C |
This Geometry Chart is provided by the Manufactuer. Chat with us if you have any questions.
Sizing
Sizing
| size | inches | cm |
|---|---|---|
| XS | 5’0” - 5’4” | 153 - 162 |
| S | 5’2” - 5’7” | 158 - 169 |
| M | 5’5” - 5’9” | 165 - 174 |
| L | 5’7” - 6’0” | 171 - 182 |
Sizing to be used as a reference only. Chat with us if you have any questions.
