2024 Intrigue X Advanced 1 Full Suspension Mountain Bike
Every bike is fully assembled, tuned, and test-ridden before pickup at your chosen DFW Bike Mart location.
Expected to ship within 3 days
Professionally built and test-ridden before it ships. Arrives mostly assembled with just minimal setup needed. See Reassembly Instructions
Delivered fully assembled and tuned by Bike Mart—ready to ride right at your doorstep within 10 miles of any DFW location.
Complete your Ride
What is the Bike Mart Return policy?
What is the Bike Mart Return policy?
Bike Mart offers a 14-day return and 30-day exchange policy in effect on qualifying items. Restocking fee may apply for "At Warehouse" Items. Read More
What Financing options does Bike Mart offer?
What Financing options does Bike Mart offer?
Financing is easier than ever at Bike Mart. With Synchrony Financial, you can choose:
- 0% APR for 6 months — on orders under $999
- 0% APR for 12 months — on orders of $1,000 or more
We also support HSA/FSA Funds with TrueMed, Shop Pay Installments and PayPal Financing.
Ship
Get your bike or equipment delivered to your home directly from Bike Mart via our FedEx or USPS Carrier partners. Adult signature is required for all bike deliveries and for equipment & gear deliveries over $500.
For orders that include a bike, it will be professionally pre-built and shipped to your home with minimal assembly needed. While we try to make it as easy as possible, basic mechanical skills and proper tools are required.
If you decide to take your bike to a local bike shop for assembly, additional fees will apply.
Pickup
We’ve made it easier than ever to get the gear and bikes you love—fast. With our Buy Online, Pick Up In Store (BOPIS) option, you can shop online and pick up your items at your convenience from any of our six DFW locations.
The best part about picking up at a Bike Mart location is that you get the same high quality service with the convenience of having the exact bike or part.
Bikes / Car Racks will be assembled and installed at no extra charge and might require additional processing time for assembly.
Delivery
When you select "Home Delivery" at checkout. Your bike will be professionally assembled and the closest Bike Mart store will call you to schedule the delivery.
We offer home delivery for bike purchases only within 10 miles of a Bike Mart location. Contact us if you live beyond 10 miles and we can discuss more options. Additional fees may apply.
In stock bikes will be delivered within 7 days. Warehouse bikes will delivered within 14 days*.
-
Advanced Composite Technology
Liv’s High-Performance Grade raw carbon material is used to produce this frameset in our own composite factory. Using state-of-the-art materials and manufacturing techniques, Liv’s Advanced-Grade Composite frames are designed to offer light weight and stiffness with optimal compliance.
-
Advanced Forged Composite Technology
A state-of-the-art, high-pressure molding process used to produce complex-shaped carbon fiber components that are lighter, stiffer and stronger than similar aluminum components.
-
Maestro Suspension Technology
Four strategically positioned pivot points and two linkages all work together to create a single floating pivot for the most active, efficient and independent suspension system on the trail.
-
OverDrive
Designed to provide precise front-end steering performance, this fork steerer tube technology uses oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
-
Tubeless System
Engineered with proprietary Dynamic Balanced Lacing technology, this tubeless ready composite WheelSystem delivers superior efficiency, pinpoint control and comfort.
Overview
Overview
The exceptionally versatile Intrigue X Advanced was designed to expand your trail capabilities, from technical descents to nimble and efficient climbs, and all the exhilarating flowy goodness in between. Extremely customizable with adjustable geometry, frame storage, and wheel options, the Intrigue X Advanced delivers extra performance and fun.
Key Performance Factors
- Performance Mid Travel Trail: Constructed with lightweight Advanced-grade composite for an agile, responsive ride, the frame also boasts integrated down tube storage — a sleek solution for additional space to store your tools and snacks. Paired with 140mm of Maestro rear suspension and 150mm of front suspension, you’ve got the ultimate trail bike that’s efficient on the ups and shreds on the downs.
- Adjustable Frame Geometry: For ultimate adjustability, the Intrigue X Advanced features flip chip – Maestro 3 and the new flip chip – headset allowing you to customize the overall riding geometry to suit the trail, your riding preferences, and rear wheel choice*. Not only can you change the head tube angle, seat tube angle, and bottom bracket height — you can now adjust your headset position to achieve either a short, mid, or long reach. These fine-tuning adjustments optimize your riding position for better handling and stability, wherever your bike takes you. *Rear wheel size change available for M and L only
- Best of Both Wheels: Frame sizes XS and S are solely designed for an MX configuration – 29-inch wheel up front and 27.5-inch wheel in the rear. This set up optimizes rear wheel travel, allows a playful and nimble rear end and a fast rolling, stable front end. Frame sizes M and L come equipped with 29-inch wheels up front and in the rear with the ability to run a 27.5-inch wheel in the rear*. This provides two unique riding characteristics – fast and comfortable or quick and nimble – allowing you to customize your set up for how and where you ride. *27.5-inch wheel sold separately for frame sizes M and L
Technical Specifications
Technical Specifications
| Sizes | XS, S, M, L |
| Colors | Raw Carbon/Chrome |
| Frame | Advanced-grade composite front and rear triangles, 140mm Maestro Suspension, flip chip – Maestro 3, flip chip – headset, integrated down tube storage |
| Fork | Fox 36 Performance Elite, 150mm, Grip 2 damper, Boost 15x110 Kabolt X, tapered, 44mm offset |
| Shock | Fox Float X Performance Elite, 185x52.5, custom tuned for Liv |
| Handlebar | Giant Contact SLR TR35, 20mm rise, composite XS: 760mm, S: 760mm, M: 760mm, L: 780mm |
| Grips | Liv Tactal Pro Single Lock-on XS/S: 120mm M/L: 130mm |
| Stem | Giant Contact SL, 35mm XS: 40mm, S: 50mm, M: 50mm, L: 50mm |
| Seatpost | Giant Contact Switch, adjustable dropper, remote XS: 140-170mm travel / 30.9 x 470mm S: 140-170mm travel / 30.9 x 470mm M: 170-200mm travel / 30.9 x 530mm L: 170-200mm travel / 30.9 x 530mm |
| Saddle | Liv Sylvia |
| Pedals | platform |
| Shifters | SRAM AXS Pod, 1x12 |
| Front derailleur | N/A |
| Rear derailleur | SRAM GX Eagle, T-Type AXS |
| Brakes | Shimano XT M8120, hydraulic, Shimano RT-66 rotors [F] 203mm, [R] 180mm |
| Brake levers | Shimano XT BL-8100 |
| Cassette | SRAM GX CS 1275 T-Type, 10x52 |
| Chain | SRAM GX T-Type |
| Crankset | SRAM GX T-Type, 30t, 55mm chainline XS: 165mm, S: 170mm, M: 170mm, L: 170mm |
| Bottom bracket | SRAM DUB, press fit |
| Rims | Giant TRX carbon WheelSystem, 30mm rim inner width XS/S: [F] 29, [R] 27.5 M/L: [F] 29, [R] 29 |
| Hubs | [F] Giant MTB alloy, 6-bolt, [R] Giant MTB alloy, 3-pawl driver, 6-bolt |
| Spokes | Sapim |
| Tires | Size XS, S, M and L, [F]: Maxxis Minion DHF 29x2.5WT, 3C Max Terra, EXO, TR, tubeless Size XS and S, [R]: Maxxis Dissector 27.5x2.4WT, 3C Max Terra, EXO, TR, tubeless Size M and L, [R]: Maxxis Dissector 29x2.4WT, 3C Max Terra, EXO, TR, tubeless |
| Extras | 3M tailgate protector, tubeless prepared, integrated down tube storage bag, max tire size 2.5", max chainring size 34t |
Parts are subject to change without notice. Chat with us if you have any questions.
Geometry
Geometry
All measurements provided in mm unless otherwise noted.
| XS | S | M | L | |
| Setting (Low/High) | LOW | MID | HIGH | LOW | MID | HIGH | LOW | MID | HIGH | LOW | MID | HIGH |
| ASeat Tube Length (mm) | 370 | 390 | 420 | 450 |
| A1A1 Seat Post Insertion Depth (mm) | 240 | 260 | 290 | 320 |
| BSeat Tube Angle (degrees) | 76.2° | 76.6° | 76.9° | 76.2° | 76.6° | 76.9° | 76.8° | 77.2° | 77.5° | 76.8° | 77.2° | 77.5° |
| CTop Tube Length (mm) | 548 | 547 | 546 | 564 | 563 | 562 | 582 | 581 | 580 | 603 | 602 | 601 |
| DHead Tube Length (mm) | 95 | 100 | 105 | 110 |
| EHead Tube Angle (degrees) | 64.4° | 64.8° | 65.1° | 64.4° | 64.8° | 65.1° | 64.4° | 64.8° | 65.1° | 64.4° | 64.8° | 65.1° |
| FFork Rake (mm) | 44 | 44 | 44 | 44 |
| GTrail (mm) | 134.2 | 131.3 | 128.3 | 134.1 | 131.3 | 128.3 | 134.1 | 131.3 | 128.3 | 134 | 131.3 | 128.3 |
| HWheelbase (mm) | 1159 | 1159 | 1158 | 1176 | 1176 | 1175 | 1202 | 1201 | 1201 | 1224 | 1224 | 1223 |
| IChain Stay Length (mm) | 440 | 439 | 438 | 440 | 439 | 438 | 440 | 439 | 438 | 440 | 439 | 438 |
| JBottom Bracket Drop (mm) | 25 | 20 | 15 | 25 | 20 | 15 | 40 | 35 | 30 | 40 | 35 | 30 |
| KStack (mm) | 615 | 613 | 610 | 620 | 617 | 614 | 621 | 619 | 616 | 626 | 623 | 620 |
| LReach (mm) | 397 | 401 | 405 | 412 | 415 | 420 | 436 | 440 | 444 | 456 | 459 | 464 |
| MStand Over Height (mm) | 730 | 734 | 738 | 733 | 737 | 742 | 745 | 749 | 754 | 767 | 771 | 776 |
| NHandlebar Width (mm) | 760 | 760 | 760 | 780 |
| OStem Length (mm) | 40 | 50 | 50 | 50 |
| PCrank Length (mm) | 165 | 170 | 170 | 170 |
| QWheel Size | [F] 29" [R | [F] 29" [R | [F] 29" [R | [F] 29" [R |
This Geometry Chart is provided by the Manufactuer. Chat with us if you have any questions.
Sizing
Sizing
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size. Available sizes may vary from country to country.
| size | inches | cm |
|---|---|---|
| XS | 4’11” - 5’4” | 150 - 163 |
| S | 5’2” - 5’7” | 158 - 169 |
| M | 5’5” - 5’9” | 164 - 175 |
| L | 5’7” - 5’11” | 170 - 181 |
Sizing to be used as a reference only. Chat with us if you have any questions.
