Stormchaser Apex Eagle SUS Gravel Road Bike
Every bike is fully assembled, tuned, and test-ridden before pickup at your chosen DFW Bike Mart location.
Expected to ship within 14 days.
Professionally built and test-ridden before it ships. Arrives mostly assembled with just minimal setup needed. See Reassembly Instructions
Delivered fully assembled and tuned by Bike Mart - ready to ride right at your doorstep within 10 miles of any DFW location.
Complete your Ride
What is the Bike Mart Return policy?
What is the Bike Mart Return policy?
Bike Mart offers a 14-day return and 30-day exchange policy in effect on qualifying items. Restocking fee may apply for "At Warehouse" Items. Read More
What Financing options does Bike Mart offer?
What Financing options does Bike Mart offer?
Financing is easier than ever at Bike Mart. With Synchrony Financial, you can choose:
- 0% APR for 6 months — on orders under $999
- 0% APR for 12 months — on orders of $1,000 or more
We also support HSA/FSA Funds with TrueMed, Shop Pay Installments and PayPal Financing.
Ship
Get your bike or equipment delivered to your home directly from Bike Mart via our FedEx or USPS Carrier partners. Adult signature is required for all bike deliveries and for equipment & gear deliveries over $500.
For orders that include a bike, it will be professionally pre-built and shipped to your home with minimal assembly needed. While we try to make it as easy as possible, basic mechanical skills and proper tools are required.
If you decide to take your bike to a local bike shop for assembly, additional fees will apply.
Pickup
We’ve made it easier than ever to get the gear and bikes you love—fast. With our Buy Online, Pick Up In Store (BOPIS) option, you can shop online and pick up your items at your convenience from any of our six DFW locations.
The best part about picking up at a Bike Mart location is that you get the same high quality service with the convenience of having the exact bike or part.
Bikes / Car Racks will be assembled and installed at no extra charge and might require additional processing time for assembly.
Delivery
When you select "Home Delivery" at checkout. Your bike will be professionally assembled and the closest Bike Mart store will call you to schedule the delivery.
We offer home delivery for bike purchases only within 10 miles of a Bike Mart location. Contact us if you live beyond 10 miles and we can discuss more options. Additional fees may apply.
In stock bikes will be delivered within 7 days. Warehouse bikes will delivered within 14 days*.
Stormchaser Apex Eagle SUS Gravel Road Bike
Bike Key Features
-
On-Bike Storage
Adventures require gear and riders should get to choose whether they carry it on their bike or on their body
-
Class 5 VRS
Comfort equates to speed and distance over rough terrain Rider benefit is inherent to the design
-
Frame Protection
Our products are built from experience — we’ve been there enough to know that a carbon fork can benefit from added protection just as much as the downtube on a suspension bike.
-
Alternator Dropouts
Adjusts chainstay length to modify ride traits and tire fit (with adjustable swing plates) Tensions chain for single-speed use (with adjustable swing plates) Gives riders upgrade options
Overview
Overview
Stormchaser Apex Eagle SUS is an adventure-ready gravel bike with suspension for seeking out the roughest tracks. The 6066-T6 alloy frame features our Class 5™ VRS to cut road chatter, and a RockShox Rudy XPLR suspension fork doubles down on comfort with 40mm of travel. A dropper post makes it easier to shift your weight to navigate obstacles and descend with complete confidence.
Technical Specifications
Technical Specifications
| Frame | Stormchaser |
| Color | Berry |
| Suspension fork | RockShox Rudy XPLR, 40 mm |
| Rear shock | N/A |
| Headset | FSA No.42 ACB |
| Seatpost | TranzX YP38 Dropper Post, 27.2, 90 mm travel |
| Stem | Salsa Guide |
| Grips/bar tape | Velo anti-slip, shock-proof silicone tape |
| Saddle | WTB Volt Medium Steel |
| Handlebar | Salsa Cowchipper |
| Front derailleur | N/A |
| Rear derailleur | SRAM Apex Eagle |
| Cassette | SRAM PG-1210, 11–50t, 12-speed |
| Chain | SRAM NX Eagle |
| Crankset | Race Face Ride, 38t |
| Shifter | SRAM Apex |
| Brake calipers | SRAM Apex HRD hydraulic |
| Rotors | SRAM CenterLine (Center Lock, 160 mm) |
| Front wheel | Shimano RS470, 12 x 100 mm hub, WTB EZR TCS 2.0 i25 29" rim, 28h (taped for tubeless, WTB tubeless valve included). Tubes installed |
| Rear wheel | Shimano RS470, 12 x 142 mm hub, WTB EZR TCS 2.0 i25 29" rim, 28h (taped for tubeless, WTB tubeless valve included). Tubes installed |
| Front tire | Teravail Rutland 700 x 47 mm, tubeless ready, Durable casing |
| Rear tire | Teravail Rutland 700 x 47 mm, tubeless ready, Durable casing |
Parts are subject to change without notice. Chat with us if you have any questions.
Geometry
Geometry
All measurements provided in mm unless otherwise noted; head tube angles are in degrees. Measurements based on: a fork measuring 435x51mm which is equivalent to an average 40mm suspension fork at 5% sag a 700x47mm tire measuring 721 mm in diameter standover (B) measured vertically to top of toptube from a position 50mm forward of BB center.
| Frame size | 49cm | 52.5cm | 54.5cm | 56cm | 57.5cm | 59cm | 61cm |
| A. Effective Top Tube (mm) | 508.0 mm | 529.0 mm | 548.0 mm | 563.0 mm | 578.0 mm | 593.0 mm | 608.0 mm |
| B. Stand Over (mm) | 697.0 mm | 736.0 mm | 766.0 mm | 794.0 mm | 807.0 mm | 829.0 mm | 851.0 mm |
| C. Reach (mm) | 359.0 mm | 363.0 mm | 365.0 mm | 374.0 mm | 383.0 mm | 392.0 mm | 402.0 mm |
| D. Stack (mm) | 535.0 mm | 549.0 mm | 568.0 mm | 587.0 mm | 606.0 mm | 625.0 mm | 644.0 mm |
| E. Total Seat Tube Length (mm) | 390.0 mm | 440.0 mm | 475.0 mm | 510.0 mm | 520.0 mm | 545.0 mm | 570.0 mm |
| F. Headtube Length (mm) | 90.0 mm | 105.0 mm | 125.0 mm | 145.0 mm | 165.0 mm | 185.0 mm | 205.0 mm |
| G. Headtube Angle (degrees) | 70.0 | 70.0 | 70.0 | 70.0 | 70.0 | 70.0 | 70.0 |
| H. Seat Tube Angle (degrees) | 75.25 | 74.0 | 73.0 | 73.0 | 73.0 | 73.0 | 73.1 |
| I. BB Drop (mm) | 64.0 mm | 64.0 mm | 64.0 mm | 64.0 mm | 64.0 mm | 64.0 mm | 64.0 mm |
| J. BB Height (mm) | 290.0 mm | 290.0 mm | 290.0 mm | 290.0 mm | 290.0 mm | 290.0 mm | 290.0 mm |
| K. Chainstay Length (mm) | 435.0 mm - 450.0 mm | 435.0 mm - 450.0 mm | 435.0 mm - 450.0 mm | 435.0 mm - 450.0 mm | 435.0 mm - 450.0 mm | 435.0 mm - 450.0 mm | 435.0 mm - 450.0 mm |
| L. Fork Length Axle to Crown (mm) | 433.0 mm | 433.0 mm | 433.0 mm | 433.0 mm | 433.0 mm | 433.0 mm | 433.0 mm |
| M. Fork Offset (mm) | 51.0 mm | 51.0 mm | 51.0 mm | 51.0 mm | 51.0 mm | 51.0 mm | 51.0 mm |
| N. Wheelbase (mm) | 1023.1 mm - 1043.3 mm | 1032.8 mm - 1052.9 mm | 1041.5 mm - 1061.6 mm | 1057.6 mm - 1077.7 mm | 1073.7 mm - 1093.6 mm | 1089.8 mm - 1109.6 mm | 1107.1 mm - 1126.9 mm |
| Crank Arm Length (mm) | 165.0 mm | 165.0 mm | 165.0 mm | 170.0 mm | 170.0 mm | 170.0 mm | 170.0 mm |
| Handlebar Width (cm) | 40.0 cm | 42.0 cm | 44.0 cm | 46.0 cm | 48.0 cm | 50.0 cm | 52.0 cm |
| Recommended Rider Height (cm) | 142.0 cm - 157.0 cm | 155.0 cm - 165.0 cm | 162.0 cm - 173.0 cm | 170.0 cm - 180.0 cm | 178.0 cm - 188.0 cm | 185.0 cm - 193.0 cm | 190.0 cm |
| Stem Length (mm) | 60.0 mm | 70.0 mm | 80.0 mm | 90.0 mm | 90.0 mm | 100.0 mm | 110.0 mm |
This Geometry Chart is provided by the Manufactuer. Chat with us if you have any questions.
