Tributary Apex 1
Fully assembled, tuned, and test-ridden—ready to ride at pickup from any DFW Bike Mart location.
Expected to ship within 3 days
Professionally built and test-ridden before it ships. Arrives mostly assembled with just minimal setup needed. See Reassembly Instructions
Delivered fully assembled and tuned by Bike Mart—ready to ride right at your doorstep within 10 miles of any DFW location.
Ship
Get your bike or equipment delivered to your home directly from Bike Mart via our FedEx or USPS Carrier partners. Adult signature is required for all bike deliveries and for equipment & gear deliveries over $500.
For orders that include a bike, it will be professionally pre-built and shipped to your home with minimal assembly needed. While we try to make it as easy as possible, basic mechanical skills and proper tools are required. For orders that include a frameset please visit our support center to make sure you have the specialty tools and skills required.
If you decide to take your bike to a local retailer for assembly, additional fees will apply.
Pickup
We’ve made it easier than ever to get the gear and bikes you love—fast. With our Buy Online, Pick Up In Store (BOPIS) option, you can shop online and pick up your items at your convenience from any of our six DFW locations.
The best part about picking up at a Bike Mart location is that you get the same high quality service with the convenience of having the exact bike or part.
Bikes / Car Racks will be assembled and installed at no extra charge
Delivery
When you select "Home Delivery" at checkout. Your bike will be professionally assembled and the closest Bike Mart store will call you to schedule the delivery.
We offer home delivery for bike purchases only within 10 miles of a Bike Mart location. Contact us if you live beyond 10 miles and we can discuss more options. Additional fees may apply.
In stock bikes will be delivered within 7 days. Warehouse bikes will delivered within 14 days*.
Tributary Apex 1
Overview
Overview
- 6061-T6 aluminum frame
- Boost suspension fork
- BOSCH Performance Line Speed class 3 mid-drive motor with smart system
- 28 mph or 45 km/h max assist
- 85 Nm max torque
- 625 watt-hour (Wh) Bosch PowerTube internal battery
- Compatible with Bosch range extender battery (sold separately)
- Class 5™ VRS
- Internal dropper post-routing
- Internal cable routing with port for integrated lighting system
- 148 x 12 Boost thru-axle rear
- SRAM UDH compatible
- Fender mounts and rear rack mounts
- Compatible with direct-mount frame bags
- Two bottle mounts inside main triangle on all sizes
- Accommodates up to 29 x 2.8" front, 2.6" rear tires
Technical Specifications
Technical Specifications
| Frame | Tributary Aluminum |
| Fork | RockShox 35 Gold, 120mm |
| Rims | WTB ST 27mm |
| Hubs | Front: Novatec D791SB-B15-CLRear: Novatec D982TSB-CL-B12-11S |
| Spokes | 2.0, Black |
| Tires | Teravail Ehline 29 x 2.3\, Durable casing |
| Crankset | FSA CK-762/IS |
| Shifters | SRAM Apex Eagle |
| Rear derailleur | SRAM Apex Eagle |
| Chain | SRAM Apex |
| Rotors | SRAM Centerline, Center Lock (203mm front, 180mm rear) |
| Brake levers | SRAM Apex Eagle |
| Handlebars | Salsa Cowchipper |
| Tape/grips | Velo anti-slip, shock-proof silicone gel tape |
| Stem | Easton EA50 |
| Headset | Acros IS52/IS52 |
| Seatpost | TranzX YSP18DL dropper, 100mm travel |
| Saddle | WTB Volt Medium Steel |
| Motor | Bosch Performance Line Speed |
| Battery | 625 watt-hour (Wh) Bosch PowerTube internal battery |
Parts are subject to change without notice. Chat with us if you have any questions.
Geometry
Geometry
| X-Small | Small | Medium | Large | X-Large | |
| A. Effective Top Tube | 535.0mm | 560.0mm | 585.0mm | 610.0mm | 635.0mm |
| B. Stand Over | 725.4mm | 737.6mm | 776.6mm | 808.8mm | 814.6mm |
| C. Reach | 373.7mm | 398.7mm | 417.6mm | 437.6mm | 457.7mm |
| D. Stack | 601.8mm | 601.8mm | 624.8mm | 643.2mm | 661.7mm |
| E. Total Seat Tube Length | 380.0mm | 405.0mm | 460.0mm | 500.0mm | 520.0mm |
| F. Headtube Length | 100.0mm | 100.0mm | 125.0mm | 145.0mm | 165.0mm |
| G. Headtube Angle | 67.0° | 67.0° | 67.0° | 67.0° | 67.0° |
| H. Seat Tube Angle | 75.0° | 75.0° | 75.0° | 75.0° | 75.0° |
| I. BB drop | 70.0mm | 70.0mm | 70.0mm | 70.0mm | 70.0mm |
| J. BB Height | 303.5mm | 303.5mm | 303.5mm | 303.5mm | 303.5mm |
| K. Chainstay length | 445.0mm | 445.0mm | 445.0mm | 445.0mm | 445.0mm |
| L. Fork Length Axle to Crown | 498.4mm | 498.4mm | 498.4mm | 498.4mm | 498.4mm |
| M. Fork Offset | 51.0mm | 51.0mm | 51.0mm | 51.0mm | 51.0mm |
| N. Wheelbase | 1094.4mm | 1119.4mm | 1148.0mm | 1175.8mm | 1203.7mm |
| O. Trail (Mechanical) | 94.9mm | 94.9mm | 94.9mm | 94.9mm | 94.9mm |
| P. Trail (Ground) | 103.1mm | 103.1mm | 103.1mm | 103.1mm | 103.1mm |
This Geometry Chart is provided by the Manufactuer. Chat with us if you have any questions.
Sizing
Sizing
| Size Designation | X-Small | Small | Medium | Large | X-Large |
| Height (Inches) | 5ft 1in - 5ft 4.2in | 5ft 4.2in - 5ft 6.9in | 5ft 6.9in - 5ft 10.1in | 5ft 10.1in - 6ft 0.8in | 6ft 0.8in - 6ft 4in |
| Height (Centimeters) | 155 - 163cm | 163 - 170cm | 170 - 178cm | 178 - 185cm | 185 - 193cm |
Sizing to be used as a reference only. Chat with us if you have any questions.
