Reach New Heights.
When the trail beckons you to traverse above tree line and into unmarked territory, the Joplin is ready to take you there. With its 120mm of VPP™ travel and 29-inch wheels, it’s the ultimate climbing partner to help you reach any summit. And when it’s time to point downhill, its head tube angle and slack geo will navigate the most rocky terrain. Whether you’re out on a solo adventure or a soul-lifting ride with friends, the Joplin will let you soar to new heights.
The reduced rolling resistance and larger footprint of 29-inch wheels inspire confidence when climbing over obstacles and helps you cover ground efficiently.
120mm VPP™ travel
VPP™ suspension can be optimized to strike the right balance between pedaling efficiency and all-out bump-chomping prowess. That means wherever you see "VPP™" you know it's tuned to perform exactly how it should for the purpose it's designed for.
Place your ride essentials securely beneath a new high-quality latch and panel in the downtube. The Glovebox comes with a fitted Tool Wallet and Tube Purse, tailored for the frame to keep your tools close to hand.
Full carbon C and CC frame
Carbon CC frames use the very best materials and production processes available, while Carbon C frames offer the same great features while adding a little more weight to save a little $. Both versions are made in our own factory, are just as strong and stiff as one another, and have a lifetime warranty.
Made to last many lifetimes
The legendary fit, finish, and quality construction put this into a league of its own. The frame, bearings, and optional Reserve wheels come with a lifetime warranty and any service is easy to do with our Rider Support pledge.
|Reach | hi/lo (mm)||405 / 403||430 / 428||455 / 453|
|Stack | hi/lo (mm)||601 / 603||610 / 612||619 / 621|
|Head Tube Angle | hi/lo||65.7 / 65.5°||65.7 / 65.5°||65.7 / 65.5°|
|Seat Tube Length (mm)||370 / 370||380 / 380||405 / 405|
|Front Center | hi/lo (mm)||708 / 708||737 / 737||766 / 766|
|BB Height | hi/lo (mm)||335 / 332||335 / 332||335 / 332|
|BB Drop | hi/lo (mm)||38 / 41||38 / 41||38 / 41|
|Wheelbase | hi/lo (mm)||1138 / 1138||1167 / 1167||1199 / 1199|
|Rear Center | hi/lo (mm)||430 / 431||430 / 431||433 / 434|
|Head Tube Length (mm)||95 / 95||105 / 105||115 / 115|
|Top Tube Length | hi/lo (mm)||555 / 556||579 / 580||602 / 603|
|Seat Tube Angle | hi/lo||76 / 75.7°||76.3 / 76°||76.7 / 76.4°|
|Standover Height | hi/lo (mm)||680 / 676||693 / 691||696 / 693|
|Frame Size||Rider Height (in)||Rider Height (cm)|
|X-Small||4'8" - 5'1"||142 - 155|
|Small||5'1" - 5'5"||155 - 165|
|Medium||5'5" - 5'9"||165 - 175|
|Fork||FOX 34 Float Factory, Grip2, 130mm -or- RockShox Pike Ultimate, 130mm|
|Rear Shock||FOX Float Factory, 190x45|
|Rims||RaceFace ARC Offset 30 29"|
Front: Industry Nine 1/1, 15x110, 6-Bolt, 28h
Rear: Industry Nine 1/1, 12x148, XD, 6-Bolt, 28h
Front: Maxxis Forekaster 29"x2.4"WT, 3C, MaxxTerra, EXO
Rear: Maxxis Forekaster 29"x2.4"WT, 3C, MaxxTerra, EXO
|Bottom Bracket||SRAM DUB 73mm MTB Wide BB|
|Crankset||SRAM X0 Eagle DUB T-Type Crankset, 32t|
|Shifters||SRAM AXS Pod Bridge|
|Rear Derailleur||SRAM X0 Eagle AXS T-Type, 12spd|
|Cassette/Freewheel||SRAM X0 Eagle T-Type, 10-52t|
|Chain||SRAM X0 Eagle T-Type, Flattop, 12spd|
|Brakes||SRAM Level Silver Stealth 4-Piston|
|Rotors||SRAM HS2 180mm|
|Handlebars||Santa Cruz 20 Carbon Bar, 760mm|
|Tape/Grips||Juliana House Grips|
|Stem||Burgtec Enduro MK3, 42mm|
|Headset||Cane Creek 40 IS Integrated Headset|
|Seatpost||OneUp V2 Dropper Post, 31.6 -or- RockShox Reverb Stealth -or- Fox Transfer|
|Saddle||Juliana Carbon Saddle|
|Charger||SRAM eTap Powerpack 1 Battery|
* Subject to change without notice.
|Matte Matcha Green / X-Small||192219344881||58-24277-163-1-798-222101||JPL20706781S|
|Matte Matcha Green / Small||192219344898||58-24277-163-2-798-222101||JPL2021234S|
|Matte Matcha Green / Medium||192219344904||58-24277-163-3-798-222101|
